Front Propeller Shaft: Inspection: Vibration

If vibration is present at high speed, inspect propeller shaft runout first.

1. With a dial indicator, measure propeller shaft runout at runout measuring points by rotating final drive companion flange with hands.
   Fig 1: Measuring Propeller Shaft Runout

   Courtesy of NISSAN MOTOR CO., U.S.A.

   Propeller shaft runout : Refer to  "PROPELLER SHAFT RUNOUT ".

   • Propeller shaft runout measuring point (Point "Δ ")

     VQ35HR

     Dimension A : 381.5 mm (15.02 in)

     VK50VE

     Dimension A : 386.5 mm (15.22 in)

   Fig 2: Measuring Propeller Shaft Runout Measuring Point

   Courtesy of NISSAN MOTOR CO., U.S.A.
2. If runout still exceeds specifications, separate propeller shaft at final drive companion flange; then change the phase between companion flange and propeller shaft by the one bolt hole at a time and install propeller shaft.
3. If runout is more than the limit value, remove and check propeller shaft.
4. Check the vibration by driving vehicle.
