Meter, Warning Lamp & Indicator -- FX35/FX50
>>
System Description
>>
Meter System
>>
ODO/Trip Meter
>>
ODO/TRIP METER : Component Parts Location
ODO/TRIP METER : Component Parts Location
Fig 1: Identifying ODO/Trip Meter Component Parts Location
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
