SHIFT POSITION INDICATOR : Component Parts Location
SHIFT POSITION INDICATOR : Component Parts Location
Fig 1: Identifying Shift Position Indicator Components
Courtesy of NISSAN DIESEL MOTOR CO., LTD.
Courtesy of NISSAN DIESEL MOTOR CO., LTD.
