Home >> Infiniti >> 2008 >> G35 Base >> Repair and Diagnosis >> Accessories & Equipment >> Gauges & Instrument Panels >> Meter, Warning Lamp & Indicator >> Function Diagnosis >> Meter System >> Shift Position Indicator >> SHIFT POSITION INDICATOR : Component Parts Location

SHIFT POSITION INDICATOR : Component Parts Location

Fig 1: Identifying Shift Position Indicator Components Location

G05223652

Courtesy of NISSAN MOTOR CO., U.S.A.
