Removal and Installation of Rear Combination Lamp Control Unit: Removal

  1. Remove luggage side box (LH). Refer to "REMOVAL AND INSTALLATION ".
  2. Remove nuts (2), and remove rear combination lamp control unit.
    Fig 1: Identifying Luggage Side Box
    G04078278Courtesy of NISSAN MOTOR CO., U.S.A.
