Instrument Lower Cover LH

WARNING: This page is about a different car, the 2005 Infiniti QX56. However, it is still accessible from the selected car via links, so may be relevant.

Remove screws using power tool, and remove instrument lower cover LH.

Pull to disconnect clips.
Disconnect harnesses from back of instrument lower cover LH.

Installation is in the reverse order of removal.

Fig 1: Disconnecting Harnesses From Back Of Instrument Lower Cover LH

Courtesy of NISSAN MOTOR CO., U.S.A.
