Body Mounting

WARNING: This page is about a different car, the 2005 Infiniti QX56. However, it is still accessible from the selected car via links, so may be relevant.

When removing, be sure to replace bolts and nuts (sealant applied bolts or self-lock nuts are used for all mounting).

Fig 1: Exploded View Of Cab And Rear Body With Torque Specifications
G02385368Courtesy of NISSAN MOTOR CO., U.S.A.
