Front Seat Belt Buckle: Removal

WARNING: This page is about a different car, the 2005 Infiniti QX56. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front seat. Refer to "REMOVAL AND INSTALLATION ".
  2. Remove the seat cushion. Refer to "SEAT CUSHION TRIM AND PAD (DRIVER) OR SEAT CUSHION ASSEMBLY (PASSENGER) ".
  3. Remove screw and seat cushion inner finisher.
  4. Remove the anchor bolt and buckle.
    Fig 1: Removing Anchor Bolt And Buckle
    G02383775Courtesy of NISSAN MOTOR CO., U.S.A.
