Section 1216 (Tires, Wheels & Tire Pressure Monitoring System (TPMS)): Wheel: Inspection

WARNING: This page is about a different car, the 2005 Infiniti QX56. However, it is still accessible from the selected car via links, so may be relevant.
  1. Check tires for wear and improper inflation.
    Fig 1: Checking Tires For Wear & Improper Inflation
    G02384953Courtesy of NISSAN MOTOR CO., U.S.A.
  2. Check wheels for deformation, cracks and other damage. If deformed, remove wheel and check wheel runout.
    1. Remove tire from wheel and mount wheel on a tire balance machine.
    2. Set dial indicator as shown in the illustration. Refer to "ROAD WHEEL ".
  3. Check front wheel bearings for looseness.
  4. Check front suspension for looseness.
