Warning Lamp And Buzzer
WARNING: This page is about a different car, the 2005 Infiniti QX56. However, it is still accessible from the selected car via links, so may be relevant.
Indicates low tire pressure or system malfunction.
WARNING LAMP AND BUZZER CONDITION TABLE
| Condition |
Warning lamp |
Buzzer |
| Less than 193 kPa (2.0 kg/cm2
, 28 psi) [Flat tire] |
ON |
Sounds for 10 sec. |
| System malfunction |
ON |
OFF |
Courtesy of NISSAN MOTOR CO., U.S.A.
