Removal and Installation: Removal

WARNING: This page is about a different car, the 2005 Infiniti QX56. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the transfer motor connector.
  2. Remove the air breather hose from the transfer motor. Refer to "REMOVAL AND INSTALLATION ".
  3. Remove the transfer motor bolts.
  4. Remove the transfer motor.
    Fig 1: Identifying Transfer Motor Bolts
    G02383184Courtesy of NISSAN MOTOR CO., U.S.A.
