Auxiliary Mechanism: Foot Position Setting Trimmer

Wind distribution ratio in FOOT mode can be set.

Operating procedures for this trimmer are as follows:

1. Begin Self-diagnosis STEP-5 mode. Refer to "SELF-DIAGNOSIS FUNCTION ".
2. Press (fan) UP switch to set system in auxiliary mode.
3. Display shows 61 in auxiliary mechanism. It takes approximately 3 seconds.
4. Press the mode switch as desired.
   Fig 1: Foot Position Setting Trimmer

   Courtesy of NISSAN MOTOR CO., U.S.A.
