Home >> Infiniti >> 2004 >> G35 x >> Repair and Diagnosis >> Accessories & Equipment >> Interior/Illumination Lights >> 2004.5 - Glove Box Lamp - Sedan >> Glove Box Lamp >> Removal and Installation >> Removal

Removal and Installation: Removal

  1. Remove instrument lower passenger panel. Refer to "INSTRUMENT PANEL ASSEMBLY ".
  2. Turn bulb socket left to release lock and remove it.

    Glove box lamp: 12V - 1.4W

    Fig 1: Removing Instrument Lower Passenger Panel
    G03328094Courtesy of NISSAN MOTOR CO., U.S.A.
