Instrument Panel Bracket



  1. Remove bolts and lower steering column. See Fig 1 .
    Fig 1: Removing Instrument Panel
    G00201761Courtesy of NISSAN MOTOR CO., U.S.A.
  2. Remove bolts, nuts and screws securing instrument panel with power tool and remove instrument panel.
    CAUTION: To install, confirm locating pins on back of instrument panel are completely inserted into holes on vehicle.
