Circuit Description

WARNING: This page is about a different car, the 2004 Lexus ES 330. However, it is still accessible from the selected car via links, so may be relevant.

The skid control ECU receives engine revolution speed signals (NE signals) from the ECM.

Fig 1: NE Signal Circuit Description
G01438943Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
