Rear Center Fascia Panel
NOTE:
- When removing with a flat-tip screwdriver or remover, wrap protective tape around the tools to prevent damage to components.
- Put on gloves to prevent hand injuries.
CAUTION:
- Use a plastic panel removal tool to remove interior trim pieces without marring the surface.
- Take care not to bend or scratch the trim and panels.
- Remove the cluster fascia panel.
(Refer to "CLUSTER FASCIA PANEL ")
- Remove the AVN head unit.
(Refer to Body Electrical System - "AVN HEAD UNIT ")
- Loosen the mounting screws and remove the rear center fascia panel (A).
- To install, reverse removal procedure.
Information
- Replace any damaged clips (or pin-type retainers).
