Repair Procedures: Removal

CAUTION:
  • Put on gloves to prevent hand injuries.
NOTE:
  • Use seat covers to avoid damaging any surfaces.
  1. Remove the tailgate trim.

    (Refer to Tailgate - "TAILGATE TRIM ")

  2. Remove the rear spoiler.

    (Refer to Body Side Molding - "REAR SPOILER ")

  3. Disconnect the hot wire connector (A) and ground connector (B).
    G13187887Courtesy of HYUNDAI MOTOR AMERICA
    G13187888Courtesy of HYUNDAI MOTOR AMERICA
  4. Using a cutter (A) knife, carefully remove the tailgate upper glass.
    G13187889Courtesy of HYUNDAI MOTOR AMERICA
  5. Cut off the sealant on the edge (B) while pulling the piano wire (A) to the left and right.
    CAUTION:
    • Put on gloves to protect your hands.
    • Heat may occur when working on the wires. Be careful not to burn your hands.
    • Be careful not to disconnect the piano wire.
      G13187890Courtesy of HYUNDAI MOTOR AMERICA
  6. Put in a piano wire (A) through the corner of the tailgate upper glass and insert wire grips into both ends of the wire.
    G13187891Courtesy of HYUNDAI MOTOR AMERICA
  7. Cut off the sealant on (A-A), (B-B), (C-C), while pulling a piano wire (A) to the left and right.
    CAUTION:
    • Put on gloves to protect your hands.
    • Heat may occur when working on the wires. Be careful not to burn your hands.
    • Be careful not to disconnect the piano wire.
      G13187892Courtesy of HYUNDAI MOTOR AMERICA
  8. Remove the tailgate upper glass (A).
    G13187893Courtesy of HYUNDAI MOTOR AMERICA
