| 1 |
Ventilation seat unit (IGN1) |
Driver ventilation LED (Low) |
Ventilation heater power |
| 2 |
Driver blower power |
Driver ventilation LED (mid) |
Driver heater power |
| 3 |
Driver blower Speed |
Driver ventilation LED (High) |
- |
| 4 |
Driver RPM input |
Driver NTC (+) |
Heater ground |
| 5 |
heater switch (Driver) |
- |
Ventilation heater power |
| 6 |
Ventilation switch (Driver) |
- |
- |
| 7 |
- |
Driver NTC (-) |
Passenger heater power |
| 8 |
Driver heater led (Low) |
Driver blower ground |
- |
| 9 |
Driver heater led (mid) |
Driver ventilation LED (Low) |
- |
| 10 |
Driver heater led (High) |
Driver ventilation LED (mid) |
Heater ground |
| 11 |
Ventilation seat unit (IGN 2) |
Driver ventilation LED (High) |
|
| 12 |
Passenger blower power |
Passenger NTC (+) |
| 13 |
Passenger blower speed |
- |
| 14 |
Passenger blower RPM input |
- |
| 15 |
Passenger heater switch |
Passenger NTC (-) |
| 16 |
Passenger ventilation switch |
Passenger blower ground |
| 17 |
- |
|
| 18 |
Passenger ventilation LED (Low) |
| 19 |
Passenger ventilation LED (mid) |
| 20 |
Passenger ventilation LED (High) |
