Repair Procedures: Inspection: Rotor

WARNING: This page is about a different variant/trim than selected.
  1. Check that there is continuity between the slip rings (C).
  2. Check that there is no continuity between the slip rings and the rotor (B) or rotor shaft (A).
    G14607353Courtesy of HYUNDAI MOTOR AMERICA
  3. If the rotor fails either continuity check, replace the alternator.
