Repair Procedures: Removal

  1. Remove the rear door trim.

    (Refer to Rear Door - "REAR DOOR TRIM ")

  2. Cut the heat-welded part with a knife and loosen the mounting screw.
  3. Remove the rear door inside handle (A).
    G14526279Courtesy of HYUNDAI MOTOR AMERICA

    Information

    • Be careful of breakage and cut the heat-welded part with a knife.
