Repair Procedures: Removal

  1. Disconnect the negative (-) battery terminal.
  2. Remove the passenger seat assembly.

    (Refer to Body - "FRONT SEAT ASSEMBLY ")

  3. Remove the heater ECU (A) after loosening mounting screws and then disconnecting the connector (B).
    G14526811Courtesy of HYUNDAI MOTOR AMERICA
