Communication Diagnosis With GDS (Self Diagnosis)

WARNING: This page is about a different car, the 2021 Hyundai Kona. However, it is still accessible from the selected car via links, so may be relevant.
  1. Communication diagnosis checks that the each linked components operates normal.
  2. Connect the cable of GDS to the data link connector in driver side crash pad lower panel.
  3. After IG ON, select the "DTC".
    G12605539Courtesy of HYUNDAI MOTOR AMERICA
