Monitor DTC Status
WARNING: This page is about a different car, the 2021 Hyundai Kona. However, it is still accessible from the selected car via links, so may be relevant.
- Plug GDS to Data Link Connector (DLC).
- Turn "ON" the ignition switch.
- Select "Diagnostic Trouble Codes (DTC)," and click "DTC Status" to check DTC information.
- Read the "DTC State" parameter.
- Is the DTC State "Present"?
"PRESENT"
- If there is any DTC related to the ESP (ESC) system, repair it first and see if DTC C174281 is cleared from the FCA/SCC module. Then go to next procedure.
"HISTORY"
- FCA/SCC module memory was not cleared after repair. Clear the DTC and go to "VERIFICATION OF VEHICLE REPAIR ".
