Repair Procedures: Inspection: Notes

  1. Check point (Warning indicator)
    NOTE: Fault conditions and normal operating conditions, refer to the owner's manual.
    NO Ref Symbol Name Color Signal Input Signal Control Check Point
    1
    G11632995
    		 Turnsignal (Left) Green CAN SJB
    CGW
    1. Multifunction Switch
    2. SJB
    3. CGW
    4. CAN Failure
    2
    G11632996
    		 Turnsignal (Right) Green CAN SJB
    CGW
    1. Multifunction Switch
    2. SJB
    3. CGW
    4. CAN Failure
    3
    G11632997
    		 Tail Lamp Green CAN SJB
    CGW
    1. Multifunction Switch
    2. SJB
    3. CGW
    4. CAN Failure
    4
    G11632998
    		 Fog Lamp Green CAN SJB
    CGW
    1. Multifunction Switch
    2. SJB
    3. CGW
    4. CAN Failure
    5
    G11632999
    		 High Beam Blue CAN SJB
    CGW
    1. Multifunction Switch
    2. SJB
    3. CGW
    4. CAN Failure
    6
    G11633000
    		 Master Symbol Yellow CAN -
    1. Reminders when service checks
    7
    G11633001
    		 Battery Charge Red CAN LDC
    CGW
    1. Charging System
    2. CGW System
    3. CAN Failure
    8
    G11633002
    		 Oil Pressure Red Hard-wired Oil Pressure
    Switch
    1. Oil Pressure Switch
    2. Hard-wired
    9
    G11633003
    		 Check Engine Yellow CAN EMS
    OBC
    CGW
    1. EMS System
    2. OBC System
    3. CAN Failure
    10
    G11633004
    		 Immobilizer Yellow CAN SMK
    CGW
    1. SMK System
    2. BCM
    3. CAN Failure
    4. Hard-wired
    11
    G00571898
    		 Parking Brake
    Brake Fluid
    EBD
    EPB    		 Red CAN CGW
    EBD
    EPB
    ABS
    TCS
    AHB
    1. CGW
    2. ABS System
    3. EPB System
    4. CAN Failure
    5. Parking Brake Switch
    6. Brake Oil Lever Sensor
    12
    G11633005
    		 ABS Yellow CAN ABS
    1. ABS System
    2. CAN Failure
    13
    G11633006
    		 ESC Yellow CAN TCS
    1. TCS System
    2. CAN Failure
    14
    G11633007
    		 ESC Off Yellow CAN TCS
    1. TCS System
    2. CAN Failure
    15
    G11633008
    		 EPB Yellow CAN EPB
    1. EPB System
    2. CAN Failure
    16
    G11633009
    		 Auto Hold White
    Yellow
    Green    		 CAN TCS
    1. TCS System
    2. CAN Failure
    17
    G11633010
    		 Seat Belt Red CAN BCM
    CGW
    1. BCM System
    2. CGW System
    3. CAN Failure
    18
    G11633011
    		 Airbag Red CAN SRSCM
    1. SRSCM System
    2. CAN Failure
    19
    G11633012
    		 EPS (MDPS) Red CAN MDPS
    1. MDPS Unit System
    2. MDPS Motor
    3. CAN Failure
    20
    G11633013
    		 TPMS Yellow CAN TPMS
    1. TPMS System
    2. TPMS Sensor
    3. CAN Failure
    21
    G11633014
    		 Fuel Warning Yellow Direct (Micom) Fuel Segment
    1. Fuel Sender Failure
    2. Wiring Failure
    22
    G11633015
    		 ECO Green CAN HCU
    CGW
    1. HCU System
    2. CGW System
    3. CAN Failure
    23
    G11633016
    		 SPORT Yellow CAN HCU
    CGW
    1. HCU System
    2. CGW System
    3. CAN Failure
    24
    G11633017
    		 CRUISE Green CAN HCU
    CGW
    1. HCU System
    2. CGW System
    3. CAN Failure
    25
    G11633018
    		 SET Green CAN HCU
    CGW
    1. HCU System
    2. CGW System
    3. CAN Failure
    26
    G11633019
    		 Cooling water temperature Red CAN EMS
    CGW
    1. EMS System
    2. CGW System
    3. CAN Failure
    27
    G11633020
    		 Service Yellow CAN HCU
    MCU
    GCU
    BMS
    TCU
    OBC
    CGW
    1. HCU System
    2. MCU System
    3. GCU System
    4. BMS System
    5. LDC System
    6. TCU System
    7. OBC System
    8. CGW System
    9. CAN Failure
    28
    G11633021
    		 Ready Green CAN HCU
    CGW
    1. HCU System
    2. CGW System
    3. CAN Failure
    29
    G11633022
    		 EV mode Green CAN HCU
    CGW
    1. HCU System
    2. CGW System
    3. CAN Failure
    30
    G11633023
    		 Regenerative Braking System (RBS) Yellow CAN AHN
    CGW
    1. AHB (RBS) System
    2. CGW System
    3. CAN Failure
    31
    G11633024
    		 HBA Green CAN LDWS
    1. HBA System
    2. CAN Failure
    32
    G11633025
    		 FCWS Yellow CAN LDWS
    1. LDWS System
    2. CAN Failure
    33
    G11633026
    		 LDWS Green
    Yellow
    White    		 CAN LDWS
    1. LDWS System
    2. CAN Failure
    34
    G11633027
    		 EV Battery Charging Red CAN OBC
    CGW
    1. OBC System
    2. CGW System
    3. CAN Failure
  2. Check point (Gauge)
    NO Name Signal Input Signal Control (Unit/Sensor) Check Point
    1 Speedometer C-CAN ABS/ESC
    1. CAN Line failure
    2 ECO/Power C-CAN HCU
    1. CAN Line failure
    3 SOC C-CAN BMS
    1. CAN Line failure
    4 Fuel Hardwire Fuel Sander
    1. Fuel sender failure
    2. Wiring failure
