Monitor GDS Data

Ignition "OFF", connect GDS.
Ignition "ON" & Engine "OFF", select "Diagnostic Trouble Codes (DTC)" mode.
Monitor diagnostic trouble code and present of trouble code.
Using a GDS, clear the DTC.

Fig 1: Screen Display - Crash Recorded In Passenger Side Restraint System With Frontal Crash (Replace ECU)
Courtesy of HYUNDAI MOTOR AMERICA
Is parameter displayed within specifications?
YES
- DTC caused by deployment of front airbag and Side airbag Passenger. Substitute with a SRSCM and check for proper operation. If the problem is corrected, replace SRSCM and then go to "VERIFICATION OF VEHICLE REPAIR " procedure.
