Repair Procedures: Inspection
WARNING: This page is about a different variant/trim than selected.
- Turn the ignition switch ON.
- Connect the GDS.
- Emit intensive light toward the photo sensor using a lamp, and check the output voltage change.
- The voltage will rise with higher intensive light and reduce with lower intensive light.
