Section 57 (Engine Control System Diagnosis (2 Of 2) (HEV))
>>
DTC P2159: Vehicle Speed Sensor 'B' Range/Performance (Wheel Speed Sensor)
>>
General Information
>>
Diagnostic Circuit Diagram
Diagnostic Circuit Diagram
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Wheel Speed Sensor Circuit Diagram
Courtesy of HYUNDAI MOTOR AMERICA
