Section 55 (Engine Cooling System (HEV))
>>
Cooling Fan (Engine)
>>
Schematic Diagrams
>>
Circuit Diagram
Circuit Diagram
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Cooling System Circuit Diagram
Courtesy of HYUNDAI MOTOR AMERICA
