Monitor Scantool Data

WARNING: This page is about a different variant/trim than selected.
  1. Connect GDS to DLC.
  2. Ignition "OFF".
  3. Ignition "ON".
  4. Checking the DTCs.
  5. Is the DTC B2467 deleted?

    YES

    • This is a intermittent problem caused by poor contact of component or Control Unit.
    • Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector.
    • Repair or replace as necessary and then, go to "VERIFICATION OF VEHICLE REPAIR " procedure.

    NO

    Fig 1: Power Relay Assembly
    G10591257Courtesy of HYUNDAI MOTOR AMERICA
