Monitor Scantool Data
WARNING: This page is about a different variant/trim than selected.
- Connect GDS to DLC.
- Ignition "OFF"
- Ignition "ON"
- Checking the DTCs.
- Is the DTC B1808 deleted?
YES
- This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector.
- Repair or replace as necessary and then, go to "VERIFICATION OF VEHICLE REPAIR " procedure.
NO
- Go to "INSPECTION/REPAIR " procedure.
