Monitor Scantool Data
WARNING: This page is about a different variant/trim than selected.
- Vehicle Parked & Ignition ON.
- Connect Scantool and select "Diagnostic Trouble Codes (DTC)" Analysis mode.
- Clear recorded DTC using Scantool.
- Operate the system within DTC "ENABLE CONDITIONS " in "GENERAL INFORMATION ".
- Is the DTC recorded?
YES
- Go to next procedure.
NO
- Fault is intermittent caused by poor contact in the sensor's and/or Control module's connector or was repaired and Control module's memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
- Repair or replace as necessary and then go to "VERIFICATION OF VEHICLE REPAIR " procedure.
