Repair Procedures: Replacement

  1. Disconnect the negative (-) battery terminal.
  2. Disconnect the connector (A) of the blower motor.
  3. Remove the blower motor (B) after loosening the mounting screws.
    Fig 1: Blower Motor & Connector
    G09135480Courtesy of HYUNDAI MOTOR AMERICA
  4. Installation is the reverse order of removal.
