Power Circuit Inspection

Engine "OFF"
Disconnect Belt tension sensor connector.
Ignition "ON" & Engine "OFF".
Measure voltage between terminal 1 of the Belt tension sensor connector and chassis ground.
Specification : Approx. 5.02V

Fig 1: Measuring Voltage Between Terminal 1 Of Belt Tension Sensor Connector And Chassis Ground
Courtesy of HYUNDAI MOTOR AMERICA
Is the measured voltage within specification?
YES
- Go to "GROUND CIRCUIT INSPECTION " procedure.
NO
- After repairing open in power circuit or short circuit of belt tension sensor, go to "VERIFICATION OF VEHICLE REPAIR " procedure
- Substitute a known-good Belt tension sensor, and check for proper operation.
  If the problem is corrected, replace the Belt tension sensor and then go to "VERIFICATION OF VEHICLE REPAIR " procedure.
