Seat Back Cover Replacement

Remove front seat assembly.
Remove the headrest.
After disconnecting the scuff band (A), remove the seat back panel (B).

Fig 1: Identifying Scuff Band & Seat Back Panel
Courtesy of HYUNDAI MOTOR CO.
Disconnect the protector (A) from the back frame.

Fig 2: Identifying Back Frame Protector
Courtesy of HYUNDAI MOTOR CO.
Disconnect the connector (A).

Fig 3: Identifying Back Frame Connector
Courtesy of HYUNDAI MOTOR CO.
Pull out the headrest guides (A) while pinching the end of the guides, and remove them.

Fig 4: Pulling Out Headrest Guides
Courtesy of HYUNDAI MOTOR CO.
After removing the hog-ring clips on the front of seat cushion and remove the seat cushion cover (A).

Fig 5: Identifying Seat Cushion Cover
Courtesy of HYUNDAI MOTOR CO.
Installation is the reverse of removal.
NOTE:
- Be sure to perform PODS re-zero with Hi-scan (PRO) after replacing parts (Passenger's)
  (Refer to AIR BAG MODULE )
