Disposal

FRONT STRUT ASSEMBLY

DISPOSAL
1. Fully extend the shock absorber rod.





2. Drill a hole on the A section as shown in the illustration to remove the gas in the cylinder.

3. NOTE: The gas coming out is harmless, but be careful of chips that may fly up when drilling. Be sure to wear a face shield and safety goggles.
