Seat Latch: Service and Repair

REAR SEAT-BACK LATCH REPLACEMENT

NOTE:
- When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.
- Take care not to bend or scratch the interior trim.

1. Remove these items:
- Seat side bolster, both sides.

2. Keep the cover (A) open, then disconnect the frame (B) from the cushion (C).
3. Remove the bolts, then remove the seat-back latch (D).
4. Installation is the reverse of removal.

NOTE: Make sure seat-back locks securely and opens properly.
