Rear Brake Shoes: Installation
To install, reverse removal procedure. Apply Lubriplate to all shoe contact points, adjuster assembly and parking brake attachment. Retract adjuster strut all the way in. To complete installation, reverse removal procedure. Apply and release parking brake lever. Depress and release brake pedal. This will automatically adjust shoe clearance.
NOTE:
The adjuster strut is marked "R" and "L" for right and left hand sides of vehicle.
