Rear Seat Front Riser Finish Cover Replacement (AL4)

Fig 1: Identifying Rear Seat Front Riser Finish Cover (AL4)
GM2116442Courtesy of GENERAL MOTORS CORP.
Callout Component Name
1 Rear Seat Inboard Riser Finish Cover
Procedure:
Remove the rear seat finish cover by pulling upward near clip locations.
2 Rear Seat Outboard Riser Finish Cover
Procedure:
Remove the rear seat finish cover by pulling upward near clip locations.
