Installation Procedure

WARNING: This page is about a different car, the 2007 Hummer H2. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View Of Throttle Body To Valve Rocker Arm Cover PCV Hose
    GM1235681Courtesy of GENERAL MOTORS CORP.
  1. Install the hose as necessary.
  2. Install the vent hose to the throttle body and the valve rocker arm cover.
    3. Fig 2: View Of PCV Hose
    GM1201537Courtesy of GENERAL MOTORS CORP.
  3. Install the PCV hose to the intake manifold and valve rocker arm cover.
  4. Install the engine sight shield. Refer to Upper Intake Manifold Sight Shield Replacement (6.0L (LQ4)) .
