Special Tools
WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2012 GMC Yukon XL, 2012 GMC Yukon, 2012 Chevrolet Tahoe, 2012 Chevrolet Suburban, and 2012 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
| Illustration | Tool Number/Description |
|---|---|
| CH 34730-262 J 34730-262 Fuel Pressure Test Gauge Adapter |
|
| CH 35800-A J 35800-A Fuel Injector Cleaner |
|
| CH 38641-C J 38641-B Diesel Fuel Quality Tester |
|
| CH 39021-380 J 39021-380 Fuel Injector Harness Adapter |
|
| CH 39021-450 J 39021-450 Fuel Injector Harness Adapter |
|
| CH 39194-C Oxygen Sensor Remover/Installer |
|
| CH 41769-1 Fuel Line Quick Connect Separator 3/8 |
|
| CH 41769-2 Fuel Line Quick Connect Separator 5/16 |
|
| CH 42220 J 42220 Universal 12-Volt Leak Detection Lamp |
|
| J 42242 Fuel Pressure Gauge Adapter |
|
| CH 42242 Fuel Pressure Test Hose Adapter |
|
| CH 42960-2 J 42960-2 Fuel Flapper Door Holder |
|
| CH 42982 J 42982 Fuel Pressure Gauge Adapter |
|
| CH 43178 J 43178 Fuel Line Disconnect Tool |
|
| CH 44175 J 44175 Fuel Composition Tester Brazil - Use local equivalent |
|
| CH 44581 J 44581 Fuel Line Disconnect Tool |
|
| CH 44603 J 44603 Injector Test Lamp |
|
| CH 45004 J 45004 Fuel Tank Drain Hose Brazil - Use local equivalent |
|
| CH 45722 J 45722 Fuel Sender Lock Ring Wrench |
|
| CH 45747 J 45747 Wrench, Fuel Sending Unit |
|
| CH 45861 J 45861 ECT Sensor Socket |
|
| CH 45873 J 45873 Fuel Return Volume Test Kit |
|
| CH 47831 Fuel Line Disconnect Tool |
|
| CH 47976 Active Fuel Injector Tester |
|
| CH 47976-60 AFIT Harness Adapter |
|
| CH 47976-75 Fuel Injector Harness Adapter |
|
| CH 48027 Digital Pressure Gauge Brazil - Use local equivalent |
|
| CH 48096 EVAP Service Access Port Tool |
|
| CH 48482 Fuel Sender Lock Ring Wrench |
|
| CH 49290 Centering Adapter Engine Subframe |
|
| CH 50375 Diesel Injector Return Line Pressure Adapter |
|
| CH 50377-A Injector Return Line Cap |
|
| CH 50378 Injector Return Leakage Test Adapter |
|
| DT 2619-01 J 2619-01 Slide Hammer |
|
| DT 36850 J 36850 Transjel Lubricant |
|
| EL 26792 J 26792 HEI Spark Tester Brazil - Use local equivalent |
|
| EL 34730-405 J 34730-405 Injector Test Lamp |
|
| EL 39021 J 39021 Fuel Injector Coil and Balancer Tester |
|
| EL 39021-210 J 39021-210 Injector Tester Adapter Box |
|
| EL 39021-460 Fuel Injector Test Adapter |
|
| EL 43244 J 43244 Relay Puller Pliers |
|
| EN 32 025 012 Sliding Hammer Adapter |
|
| EN 37281-A J 37281-A Injector Remover |
|
| EN 37287 J 37287 Fuel Line Shut-Off Adaptors (Flex Fuel) |
|
| EN 38522 J 38522 Variable Signal Generator |
|
| EN 39313 J 39313 Spark Plug Port Adapter |
|
| EN 41413-311 J 41413-311 EVAP Plug |
|
| EN 41413-VLV J 41413-VLV EVAP Service Port Vent Fitting Brazil - Use local equivalent |
|
| EN 41769 J 41769 KM J 41769 Fuel Line Disconnect Tool Set |
|
| EN 43936 J 43936 Fuel Pressure Adapter Cap |
|
| EN 43937 J 43937 Fuel Pressure Adapter Lines |
|
| EN 44602 J 44602 Injector Test Adapter |
|
| EN 45873-30 J 45873-30 Injector Flow Test Adapter |
|
| EN 46091 J 46091 Charge Air Cooler Tester |
|
| EN 46091-5 J 46091-5 Charge Air Cooler Tester Adapter |
|
| EN 46091-15 J 46091-15 Engine Pressure Test Adapter |
|
| EN 46577 Oxygen Sensor Remover/Installer |
|
| EN 46594 J 46594 Fuel Injector Puller |
|
| EN 46786 32 025 013 Injector Removal Tool |
|
| EN 46790 32 025 005 Puller |
|
| EN 46843 Quick Connect Release Tool |
|
| EN 46999 Displacement On Demand Electric Tool |
|
| EN 47603 Compression Gauge Adapter |
|
| EN 47632 32 025 010 Cleaning Tool |
|
| EN 47969 Fuel Supply Diagnostic Hose |
|
| EN 48248 Cylinder Compression Pressure Gauge |
|
| EN 48266 Injector Seal Installer/Sizer |
|
| EN 48278 Sub Fuel Pump Locking Ring Remover/Installer |
|
| EN 48279 Main Fuel Pump Locking Ring Remover/Installer |
|
| EN 48303 Fuel Filter Housing Holder |
|
| EN 48304 Fuel Filter Locker Installer/Remover |
|
| EN 48357 Injector Remover |
|
| EN 48536 Frame Support Tool (Engine Lower 65 mm Kit) |
|
| EN 48565 EGR Test Harness |
|
| EN 48896 HP Fuel Pump Installation Alignment Gauge |
|
| EN 49232 Fuel Pump Lock Ring Remover |
|
| EN 49774 Fuel Injector Remover |
|
| EN 49799 Fuel Pressure Gauge Adapter |
|
| EN 83 95 261 Fuel Line Tool |
|
| GE 23738-A J 23738-A Vacuum Pump |
|
| GE 41413-A J 41413-A Evaporative Emissions System Tester (EEST) Brazil - Use local equivalent |
|
| GE 41413-300 J 41413-300 EVAP Cap and Plug Kit Brazil - Use local equivalent |
|
| GE 41413-SPT J 41413-SPT High Intensity White Light Brazil - Use local equivalent |
|
| GE 41415-40 J 41415-40 Fuel Tank Cap Adapter |
|
| GE 41415-50 J 41415-50 Fuel Tank Cap Adapter |
|
| GE 41415-50A 2nd Design Interrupted Thread Fuel Tank Cap Adapter |
|
| J 22610 Keystone Clamp Pliers |
|
| J 24460-A Cooling System Pressure Tester |
|
| J 25070 Heat Gun 260-399°C (500-750°F) |
|
| J 34730-375 Injector Test Lamp |
|
| J 36012-A Ignition System Diagnostic Harness |
|
| J 38491 Spark Plug Boot Removal Tool |
|
| J 39765 Fuel Sender Locknut Wrench |
|
| J 41415-30 Fuel Tank Cap Adapter Brazil - Use local equivalent |
|
| J 41515-A Glow Plug Socket |
|
| J 42598-B Vehicle Data Recorder |
|
| J 43094 Spark Plug Boot Puller |
|
| J 43883 Ignition System Diagnosis Harness |
|
| J 44402 Fuel Tank Sending Unit Wrench |
|
| J 45059 Angle Meter |
|
| KM 6009 Remover/Installer |
|
| KM 807 Closure Plugs |
