Body Harness Passenger Compartment (Without E52)

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2011 GMC Yukon XL, 2011 GMC Yukon, 2011 Chevrolet Tahoe, 2011 Chevrolet Suburban, and 2011 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
Body Harness Passenger Compartment (Without E52)

Component Name Callout
G301 1
G303 2
G302 3
G304 4
Fig 1: Body Harness Passenger Compartment (Without E52)
GM2077176Courtesy of GENERAL MOTORS CORP.
