Removal Procedure

WARNING: This page is about a different car, the 2007 Hummer H2. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the hood.
  2. Remove the side hood bumper. Refer to Hood Side Bumper Replacement .
    3. Fig 1: Upper Hood Latch
    GM859395Courtesy of GENERAL MOTORS CORP.
  3. Remove the upper hood latch (1) from the hood.
    4. Fig 2: Hood Latch Receiver
    GM859398Courtesy of GENERAL MOTORS CORP.
  4. Remove the two fasteners (1) that retain the hood latch receiver (2) to the fender extension.
  5. Remove the hood latch receiver (2) from the fender extension.
