Dirt or Dust Detective Function (CLEAN FRONT WINDSHIELD Indication)

If the message Some Driver Assist System Cannot Operate: Clean Front Windshield appears on the MID, the camera lens or the windshield has enough dirt so that the camera view is obstructed. The Auto High-Beam stops operating.

Clean any dirt or contamination on the camera lens or the windshield. Once the camera's view is unobstructed, the MID turns off and the Auto High-Beam automatically turns back to ON.

GHH306275Courtesy of HONDA, U.S.A., INC.
