Driver's Dashboard Lower Cover Removal/Installation

NOTE: Take care not to scratch the dashboard and related parts.
  1. Remove the driver's dashboard lower cover (A).
    1. Turn the lock knob (B) 90°.
    2. Gently pull out the left side to release the hooks (C).
    3. Pull out the panel to release the hooks (D).
    Fig 1: Removing Driver's Dashboard Lower Cover
    G01400419Courtesy of AMERICAN HONDA MOTOR CO., INC.
  2. Install the cover in the reverse order of removal, and push the hooks into place securely.
