Parking Brake Switch

  1. Remove the console. See Fig 1 .
    Fig 1: Removing Console
    G00128190Courtesy of AMERICAN HONDA MOTOR CO., INC.
  2. Disconnect the connector (A) from the switch (B). See Fig 2 .
  3. Check for continuity between the positive terminal and the body ground.
  4. With the brake lever up, there should be continuity.
  5. With the brake lever down, there should be no continuity.
Fig 2: Identifying Parking Brake Switch Test Connectors
G00126392Courtesy of AMERICAN HONDA MOTOR CO., INC.
