DTC B1022 - DRIVER DEPLOYMENT LOOP RESISTANCE LOW (3 of 3)

NOTE: Test numbers refer to specific step numbers on diagnostic chart and may skip step numbers. No information has been left out. For circuit number identification, see WIRING DIAGRAM  .

1. 10)  This test checks for a short from CKT G/R to CKT G.
2. 12)  This test checks for short from CKT G/R to CKT Y.

Fig 1: DTC B1022 - Passenger Deployment Loop Resistance LOW (3 Of 3)

Courtesy of GENERAL MOTORS CORP.
