DTC B1022 - DRIVER DEPLOYMENT LOOP RESISTANCE LOW (2 of 3)

NOTE: Test numbers refer to specific step numbers on diagnostic chart and may skip step numbers. No information has been left out. For circuit number identification, see WIRING DIAGRAM  .

1. 6)  This test isolates malfunction to one side of air bag steering wheel module coil Yellow  2-way connector located near base of steering column.
2. 7)  This test checks if malfunction is in air bag steering wheel module coil or in air bag steering wheel module.

Fig 1: DTC B1022 - Passenger Deployment Loop Resistance LOW (2 Of 3)

Courtesy of GENERAL MOTORS CORP.
