Diagnostic Aids
An intermittent condition may be caused by a poor connection, rubbed-through wire insulation, or a broken wire inside insulation. Check ECM harness connectors for backed-out terminals, improper mating, broken locks, improperly formed or damaged terminals, poor terminal-to-wire connection, and damaged harness.
