DTC 11, Short To Ground In Steering Column Circuit (2 Of 5)

NOTE: Test numbers refer to test numbers on diagnostic chart. For circuit number identification, see WIRING DIAGRAMS.

1. 4)  Checks for a short to ground in D- circuit.
2. 5)  Checks for a short to ground in SL+ circuit.

WARNING: To avoid air bag deployment and injury when trouble shooting system, only use test equipment specified in diagnostic charts.

Fig 1: Flowchart, DTC 11 - Short To Ground In Steer. Col. Cir. (2 of 5)

Courtesy of GENERAL MOTORS CORP.
