2ND & 3RD Clutch Assemblies
- With 2nd clutch assembly on bench, align drive plates in drum. Insert 3rd clutch drum and input shaft through top of 2nd clutch drum, seating 3rd clutch drum splines with 2nd clutch plate splines.
- Holding clutch assemblies by input shaft, lower into transmission case, indexing 2nd clutch drum ring gear with long planetary pinion gear teeth.
